S	g6
2.00~ 3.00	-0.002 -0.008
3.01~ 6.00	-0.004-0.012
6.01~10.00	-0.005-0.014
10.01~18.00	-0.006-0.017
18.01~29.00	-0.007-0.020

 ■Diamond Part Dimensions

S	(W)
2.00~ 2.99	0.8
3.00~ 6.00	1.5
6.01~10.00	3
10.01~15.00	4
15.01~29.00	5.5

Select Type, Material Code and D Dimension. (For details, see ordering example.)


Part Number

0.01mm Increment

1mm Increment

Z

M

Type

Material Code

Type

Shape, Material Code Z Dim. Fixed

D

P

S (P>S)

L

B

Fixed

Selectable

Z Fixed

Z Selectable

①Round Tipped (S   0 -0.02) KJP (Sg6) KJPG

D DH DS DSC

DZ DHZ

②Diamond-Tipped (S   0 -0.02) KJP

DD DDH

8

2.50~ 6.00

2.00~ 5.50

5~25 When P≤3.99 L≤Px4 For 304 Stainless Steel, L≤Px5

5~25 When S≤2.99 B≤Sx4 For 304 Stainless Steel, B≤Sx5

50

* 10 20 30 40

M4

10

2.50~ 8.00

2.00~ 7.50

M5

12

2.50~10.00

2.00~ 9.50

16

3.50~14.00

3.00~13.50

20

10.00~18.00

5.00~17.00

25

15.00~23.00

8.00~22.00

10L

10.00~16.00

5.00~15.00

30 40

12L

12.00~20.00

6.00~19.00

(L+B≤50)

16L

16.00~25.00

8.00~24.00

For longer pins, see >> Click here

20L

20.00~30.00

10.00~29.00

[ ! ]Z dimension can be specified for Handle Length Selectable Type only.
*Z dimension 10 and 20 are available only when P≥5 and pin length (L+B)≤30 only.
[ ! ]Dowel holes are not provided on products with Z=10.
[ ! ]Large Head Type (D=10L~20L) is available for 1045 Carbon Steel only.
[ ! ]Thin diamond can not be specified. (For S≤8, B≤Sx3)
